First time serious over clock e8400

[ajhtiredwolf]

My mistake, mch wasn't even listed. Are you sure that I should use that bios version? It says that it is in Beta. The bios that I have now is f6

[Lsdmeasap]

Yes, I always use the latest beta. They have fixes and improvements LONG before they are made final. F6 is very old

Can you try the hotkey, G31 or P31 may not have MCH but best to check and be sure. On the MAIN page of the BIOS press control + F1 and the screen will flash, then go into the MIT Section and see if you see MCH voltage.

I can check your BIOS if you like, I will go ahead and check out F10f now while I wait on your reply

[Lsdmeasap]

Looks like only GTL Ref 1 and FSB Overvoltage and Deovervoltage control in your BIOS, sorry no MCH Ref.

You may have a hard time getting 2x2GB stable due to this issue

[ajhtiredwolf]

Alright bios is updated to the latest version, lets go ahead and try 425 first, and then move to 450 if it works.

[Lsdmeasap]

try this then for 425 FSB

Robust Graphics Booster___________ [Auto or Fast]
CPU Clock Ratio ____________ [9]
Fine Clock Ratio ____________[0.0]
CPU Host Clock Control_ [Enabled]
CPU Host Frequency (MHz)__________ [425]
PCI Express Frequency (Mhz)_______ [100]
C.I.A. 2__________________________ [Disabled]
System Memory Multiplier (SPD)____ [2.40] =1020Mhz
DRAM Timing Selectable_______ SPD __ [Manual]

Performance Enhance = [Standard]

CAS Latency Time________________ 5
Dram RAS# to CAS# Delay_________ 5
Dram RAS# Precharge Delay_______5
Precharge Delay (tRAS)__________ 15

ACT to ACT Delay (tRRD)_________ 3-4
Rank Write to READ Delay________ 3-6
Write to Precharge Delay_________ 4-6
Refresh to ACT Delay______________ 52-62
Read to Precharge Delay__________ 3-5
Static tRead Value_______________ 7-8
Static tRead Phase Adjust________ [Auto]


System Voltage Control____ [Manual]
DDR2 OverVoltage Control__ [+0.300V]
PCI-E OverVoltage Control_ [+0.1V]
FSB OverVoltage Control___ [+0.1V]
CPU Voltage Control_______ [1.34-1.38]

Limit CPUID Max. to 3.....................: [Disabled]
No-Execute Memory Protect............: [Enabled]
CPU Enhanced Halt (C1E)................: [Disabled]
C2/C2E State Support....................: [Disabled]
x C4/C4E State Support..................: [Disabled]
CPU Thermal Monitor 2(TM2) ...........: [Enabled]
CPU EIST Function.........................: [Disabled]
Virtualization Technology................: [Disabled] Enabled if you use Vmware/Virtual PC

Integrated Peripherals
Legacy USB Storage Detect___________________[Disabled] *Note* Must be enabled to flash from USB

[ajhtiredwolf]

Didn't work, it reset itself back to defaults. but there are some options that you didn't list. What should the cpu gtlref voltage ratio be set to?, what should the fsb DeOvervoltage control be set to? PCI express over voltage isn't an option.

[ajhtiredwolf]

Btw how is it that you are determining the voltages so that I can do it myself in the future?
